IAI America RCM-101-USB - Manual (Page 255)

14.
Appendix
243
14. Appendix
14.1 Parameter (Factory Default Setting) Initializing Method
Note: Parameters (factory default setting) can be initialized only for PCON, ACON, SCON, ERC2, ERC3,
ROBONET, ASEP, PSEP, DSEP, MSEP and MSCON controller.
Note : Note that parameters set by user are changed to the factory default parameters when parameters
(factory default setting) are initialized.
(1) Right click a blank part of the toolbar (Appendix Fig. 14.1) while pressing the Ctrl key, then input password
window as shown in Fig. 14.2 is displayed.
Fig. 14.1 Menu Bar
Fig. 14.2 Input Password Window
(2) Input the password (5119) on the displayed input password window, then the “Controller Initialization”
(factory default setting) menu is displayed (Fig. 14.3).
(Note) The password inputted once is effective until the application ends.
Fig. 14.3 Menu Bar (Parameter Initialization (Factory Default Setting))
Right-click the blank part of
the tool bar while pressing Ctrl.
