5. Editing Position Data on CON Controllers and Older Models
51
Simultaneous Movement of Multiple Axes
Multiple axes simultaneous start button
You can use this button to simultaneously move the selected axes, from among the multiple axes currently
connected by link cables.
Click the multiple axes simultaneous start button in the positioning setting area.
Fig. 5.20 Multiple Axes Simultaneous Start Button
The “Start multiple axes simultaneously” window will open.
Fig. 5.21 Start Multiple Axes Simultaneously Window
Axis number Position
Checkbox
Step, continue and stop
buttons from the left
