3. Main W
indow
35
(5) Setup
[1] [Application Setup]
Set up the application (baud rate and ports).
[Controller Other than ASEP, PSEP, DSEP and MSEP]
You can separately change the system passwords needed to open the position data edit window and
parameter setting window. Note that if the password for the position data edit window is “0000” (factory-set
password), you need not enter any password to open the position data edit window.
[ASEP, PSEP, DSEP and MSEP Controller]
You can change the passwords needed to open the parameter setting window and initial setting window.
With ASEP, PSEP, DSEP and MSEP controllers, the password for the position data edit window is set by
parameter No. 20. Note that if the password for the position data edit window is “0000” (factory-set
password), you need not enter any password to open the position data edit window.
[2] [Controller Setup]
[Reconnect]: Reconnect the axes.
If the software connects to multiple controllers linked by controller link cables, always select Reconnect
after cycling power to a connected controller to which the teaching pendant is not connected directly.
[Disconnect] : Cuts the communication with all the connected axes.
[Assign Axis Number] : Available only for types not equipped with axis number setup rotary
SW.
The last axis number will be the axis number set for the last axis
number* on the setting of application window.
[Reset Software] : Reset (restart) the software.
* RCP, RCS and E-Con cannot reset the software.
[Initial Setting for SEP Controller] : Select the operation pattern of your SEP controller (from PIO patterns
0 to 6) and set the operation mode (single-solenoid, double-solenoid,
etc.), among others.
[Time Setting] : Set the time for SCON-CA, PCON-CA, ERC3 PIO Converter, MSEP
and MSCON.
* Only the time for SCON-CA, PCON-CA and ERC3 PIO Converter
(Software Version V8.03.00.00 or later), MSEP and MSCON can be
set.
[Load Cell Calibration] : Perform the load cell calibration on RCS2-RA13R actuator equipped
with load cell.
[Actuator Replacement] : Reset the counter to 0 for the total travel times and total driving
distance [m] in the maintenance information. Input the password 5119
and press OK.
[Fan Replacement] : Reset the counter to 0 for the total fan driving time [days] in the
maintenance information. Input the password 5119 and press OK.
