13. Frequency
Analysis Function for SCON-CA
Controller
Anti-V
ibration Control
231
[4] Frequency resolution
The frequency resolution of FFT analysis result is shown. The distance between adjacent plotting points
on the FFT analysis result data graph is indicated visually in [Hz].
(Note) This value is determined by the analysis time, which in turn is determined in the “sampling”
window, and will not change even when settings are changed on the “FFT analysis result”
window.
[5] Axis number selection
Set the axis number to forward the parameters to.
When new controller data is imported, the axis number selected in the “measurement data selection”
window is set. Otherwise, you can select any axis number to which data can be forwarded.
[6] Parameter set number selection
Select one of parameter sets 1 to 3 containing the parameter in which the set frequency will be set.
[7] Forward to Controller button
Clicking this button forwards the parameters to the controller.
(Note) If one of the following conditions applies, the parameters cannot be forwarded to the controller:
• The connected controller does not support the vibration control function.
• The system is offline.
