9-26 Fusion-MPT SAS BIOS and Setup Utility
Copyright © 2001, 2002, 2007 by LSI Logic Corporation. All rights reserved.
creating a new array. To begin the process, you highlight one of the
options and press Enter. (See
Section 9.4, “Performing Configuration
Tasks,” for detailed instructions on creating arrays and other tasks.)
Figure 9.14 Select New Array Type Screen
9.3.12.2 Create New Array
The Create New Array screen appears after you select an array type.
This screen enables you to select disks for a new array.
Figure 9.15
shows the Create New Array screen.
Figure 9.15 Create New Array Screen
LSI Logic MPT Setup Utility v6.xx.xx.xx
Select New Array Type -- SAS1068
Create IM Volume Create Integrated Mirror Array of 2
disks plus an optional hot spare. Data
on the primary disk may be migrated.
Create IS Volume Create Integrated Striping array of
2 to 8 disks.
ALL DATA on array disks will be DELETED!
Esc = Exit Menu F1/Shift+1 = Help
Enter = Choose array type to create Esc = Return to Adapter Properties
LSI Logic MPT Setup Utility v6.xx.xx.xx
Create New Array -- SAS1068
Array Type: IM
Array Size(MB) 34332
Slot Device Identifier RAID Hot Drive Pred Size
Num Disk Spr Status Fail (MB)
1 MAXTOR ATLAS15K2_36SAS BG34 [Yes] [No] Primary --- 35074
2 MAXTOR ATLAS15K2_36SAS BG34 [Yes] [No] Secondary --- 35074
8 MAXTOR ATLAS15K2_36SAS BG34 [No] [Yes] Hot Spare --- 35074
11 MAXTOR ATLAS15K2_36SAS BG34 [No] [No] Max Dsks --- 35074
Esc = Exit Menu F1/Shift+1 = Help
Space/+/- = Select disk for array or hot spare C = Create array
