4-40 Description of Features
1503-UM054C-EN-P – June 2013
There is a Red/Green bi-color LED which is used to indicate the
DeviceNet network operating status. Only the Red or Green LED
should be on at any one time.
Table 4.H shows the operation of the DeviceNet Network Status
LED as well as the faults/warnings that it indicates.
Table 4.H – DeviceNet Network Status LED
Fault/Warning Red LED Green LED Description
None Off Off No power from IB or DeviceNet
Warning Off Flashing IE determining network baud rate
or device is in idle mode
Warning Off Flashing On-line but not allocated to
master
None Off Solid On Normal operation & allocated to
master
Warning Flashing Off Output fault or configuration error,
or I/O connection timed out, or
illegal DeviceLogix program
downloaded to this device
Fault Solid On Off Bus Off or Duplicate DeviceNet
address detected or
Invalid baud rate or other
unrecoverable fault
No Power from IB or DeviceNet
This is a Normal condition if there are no input power sources to the
IntelliVAC Plus module. If this condition exists and there is at least
one source of external power supplied to the IntelliVAC Plus unit
then a serious problem may exist. Refer all servicing to qualified
service personnel or see the Troubleshooting section in Chapter 10.
The Advanced module has no power from either the Basic module or
from DeviceNet.
The causes of the loss of Basic module power are either that there is
no 120/240V main input power to the IntelliVAC Plus module or
that this input voltage is <50Vrms. Also, the internal DC power
source on the Basic module has failed or the internal DC power
source on the Advanced module has failed, or both. Also, there is no
DeviceNet power or the internal DC power source of the advanced
module has failed.
The DeviceNet status LED is off.
Network Status
(DeviceNet)
