Chapter
1
1503-UM054C-EN-P –June 2013
Product Description
Introduction This document contains information for the Allen-Bradley Bulletin
1503VC IntelliVAC™ Plus control module. The Bulletin 1503VC is
used to control the Allen-Bradley Bulletin 1502 vacuum contactors that
are a significant component of the Bulletin 1500/1900 CENTERLINE
Medium Voltage Motor Controllers and Bulletin 7000 Medium
Voltage Drives offered by Rockwell Automation.
The IntelliVAC Plus is an enhanced version of the IntelliVAC control
module which is typically provided as the standard means of
controlling the vacuum contactors in medium voltage controllers and
drives. IntelliVAC Plus may be supplied with IntelliVAC Multi-
Contactor (MC) modules in control schemes that require more than one
vacuum contactor. In this case there will be one IntelliVAC Plus unit
and up to four IntelliVAC MC units.
An IntelliVAC Plus control module may also be provided as a loose
component, for application with a Bulletin 1502 contactor by a third
party (OEM).
Scope This document applies to the following equipment:
Description Series
IntelliVAC Plus Module A
IntelliVAC Multi-Contactor (MC) E
Refer to the following publications 1503-UM05_ _-EN-P for
information related to the following IntelliVAC equipment:
Series E designs.
Description Series Publication
IntelliVAC Module A to B 1503-UM051_-EN-P
IntelliVAC Module C to D 1503-UM052_-EN-P
IntelliVAC Module E 1503-UM053_-EN-P
