Parameters B-73
1503-UM054C-EN-P – June 2013
TDUV Time Setting from IB5 DIP Switches
[IB 5 TDUV Time DIP Setting]
Parameter Number:
132,_,_,_,_.
Access rule: Get
Data Type: USINT
Object Mapping: 0x384-5-58
Group: Configuration
Units: see table
Minimum Value: 0
Maximum Value: 3
Default Value: 0
This parameter allows the user to view the Time Delay Undervoltage
Setting set from the IB5 DIP switches. The Time Delay
Undervoltage Setting is initially set by the IB5 DIP switches but can
be over-ridden by Parameter #137 after which time the original IB5
DIP switch settings will no longer be used. See TDUV in Chapter 8
and Table 8.E.
Table B.32 – TDUV Time Setting From IB5 DIP Switches
Value Enum Text Description
0 0.2 Sec 0.2 Sec TDUV setting from IB5 DIP switches
1 0.5 Sec 0.5 Sec TDUV setting from IB5 DIP switches
2 1.0 Sec 1.0 Sec TDUV setting from IB5 DIP switches
3 2.0 Sec 2.0 Sec TDUV setting from IB5 DIP switches
TDUV Time Setting for IB1
[IB 1 TDUV Time]
Parameter Number:
133,113,93,73,52
Access rule: Get/Set
Data Type: UINT
Object Mapping: 0x384-1-50
Group: Configuration
Units: Seconds error in EDS file
Minimum Value: 0.2
Maximum Value: 2.0
Default Value: 0.2
This parameter allows the user to view and set the Time Delay
Undervoltage setting for the IB1 module. The Time Delay
Undervoltage setting is the time allowed for contactor IB1 to remain
operational when the mains input voltage goes below the minimum
operating voltage (see Electrical Specifications section for both
Close and Hold modes). See TDUV Programmability in Chapter 4
for a detailed description of this feature.
