Parameters B-33
1503-UM054C-EN-P – June 2013
DC Bus Voltage for IntelliVAC Base Unit #5
[IB 5 DC Bus Voltage]
Parameter Number: 60,_,_,_,_.
Access rule: Get
Data Type: FLOAT
Object Mapping: 0x384-5-12
Group: Control
Units: Volts
Minimum Value: 00.000V
Maximum Value: 399.999V
Default Value: 00.000V
This parameter allows the user to view the DC value for the DC Bus
voltage on the IntelliVAC Basic Module #5.
Enhanced Module Hardware Input Status
[IE Hardware Inputs]
Parameter Number: 61,49,37,25,13.
Access rule: Get
Data Type: BYTE
Object Mapping: 0x4-11-3
Group: Control
Units: -
Minimum Value: -
Maximum Value: -
Default Value: None
This parameter allows the user to view the status of the eight (8)
hardware inputs. Each bit position of the parameter defines the state
of one of the hardware inputs. If the voltage to an input is lower than
the maximum required, as defined in the Electrical Specifications in
Table 1.A, then the corresponding bit will indicate a ‘0’. If the
voltage to an input exceeds the minimum required, as defined in the
Electrical Specifications in Table 1.A, then the corresponding bit will
indicate a ‘1’.
Table B.4 – Enhanced Module Hardware Input States
Bit Enum Text Description
0 Bit 0: DLX Input 1 Status of DeviceLogix Input #1
1 Bit 1: DLX Input 2 Status of DeviceLogix Input #2
2 Bit 2: DLX Input 3 Status of DeviceLogix Input #3
3 Bit 3: DLX Input 4 Status of DeviceLogix Input #4
4 Bit 4: DLX Input 5 Status of DeviceLogix Input #5
5 Bit 5: DLX Input 6 Status of DeviceLogix Input #6
6 Bit 6: DLX Input 7 Status of DeviceLogix Input #7
7 Bit 7: DLX Input 8 Status of DeviceLogix Input #8
