Parameters B-181
1503-UM054C-EN-P – June 2013
Status Word for the MC System
[MC System Status]
Parameter Number: 346,285,224,163,101.
Access rule: Get/Set
Data Type: WORD
Object Mapping: 0xB4-1-127
Group: Diagnostics
Units: -
Minimum Value: 0
Maximum Value: 0xFFFF
Default Value: 0
This parameter allows the user to view the MC System Status Word.
If a bit is ‘0’ then the fault or warning is not present. If a bit is a ‘1’
then the fault or warning is present. See Table 4.H in Chapter 4 for a
detailed description of each of the MC System Status Word bits.
Table B.45 – Status Word for MC System
Bit Enum Text Description
0 Aggregate warning status Aggregate warning status
1 Aggregate fault status Aggregate fault status
2 IE warning status IE warning status
3 IE fault status IE fault status
4 IB5 warning status IB5 warning status
5 IB5 fault status IB5 fault status
6 IB4 warning status IB4 warning status
7 IB4 fault status IB4 fault status
8 IB3 warning status IB3 warning status
9 IB3 fault status IB3 fault status
10 IB2 warning status IB2 warning status
11 IB2 fault status IB2 fault status
12 IB1 warning status IB1 warning status
13 IB1 fault status IB1 fault status
14 System running status System running status
15 System ready status System ready status
