B-44 Parameters
1503-UM054C-EN-P – June 2013
Status of the Change Of State Mask [Status COS Mask]
Parameter Number: 82,70,58,46,33.
Access rule: Get/Set
Data Type: DWORD
Object Mapping: 0xB4-1-111
Group: Communication
Units: -
Minimum Value: 0
Maximum Value: 0xFFFFFFFF
Default Value: 0
This parameter allows the user to view and set the status of the COS
Mask. When a bit is set, that bit will not trigger a status COS
message.
Table B.12 – Status COS Mask Bit Definition
Bit Enum Text Description
0 Status COS Mask Bit 0 Status COS Mask Bit 0 “IE: Input 0”
1 Status COS Mask Bit 1 Status COS Mask Bit 1 “IE: Input 1”
2 Status COS Mask Bit 2 Status COS Mask Bit 2 “IE: Input 2”
3 Status COS Mask Bit 3 Status COS Mask Bit 3 “IE: Input 3”
4 Status COS Mask Bit 4 Status COS Mask Bit 4 “IE: Input 4”
5 Status COS Mask Bit 5 Status COS Mask Bit 5 “IE: Input 5”
6 Status COS Mask Bit 6 Status COS Mask Bit 6 “IE: Input 6”
7 Status COS Mask Bit 7 Status COS Mask Bit 7 “IE: Input 7”
8 Status COS Mask Bit 8 Status COS Mask Bit 8 “IB1: Aux Status”
9 Status COS Mask Bit 9 Status COS Mask Bit 9 “IB1: Close Status”
10 Status COS Mask Bit 10 Status COS Mask Bit 10 “IB1: Open Status
11 Status COS Mask Bit 11 Status COS Mask Bit 11 “IB2: Aux Status”
12 Status COS Mask Bit 12 Status COS Mask Bit 12 “IB2: Close Status”
13 Status COS Mask Bit 13 Status COS Mask Bit 13 “IB2: Open Status”
14 Status COS Mask Bit 14 Status COS Mask Bit 14 “IB3: Aux Status”
15 Status COS Mask Bit 15 Status COS Mask Bit 15 “IB3: Close Status”
16 Status COS Mask Bit 16 Status COS Mask Bit 16“IB3: Open Status”
17 Status COS Mask Bit 17 Status COS Mask Bit 17 “IB4: Aux Status”
18 Status COS Mask Bit 18 Status COS Mask Bit 18 “IB4: Close Status”
19 Status COS Mask Bit 19 Status COS Mask Bit 19 “IB4: Open Status”
20 Status COS Mask Bit 20 Status COS Mask Bit 20 “IB5: Aux Status”
21 Status COS Mask Bit 21 Status COS Mask Bit 21 “IB5: Close Status”
22 Status COS Mask Bit 22 Status COS Mask Bit 22 “IB5: Open Status”
23 Status COS Mask Bit 23 Status COS Mask Bit 23 “unused”
24 Status COS Mask Bit 24 Status COS Mask Bit 24 “Protection Status”
25 Status COS Mask Bit 25 Status COS Mask Bit 25 “Speed SW FWD Status”
26 Status COS Mask Bit 26 Status COS Mask Bit 26 “Speed SW REV Status”
27 Status COS Mask Bit 27 Status COS Mask Bit 27 “Isolation SW Status”
28 Status COS Mask Bit 28 Status COS Mask Bit 28 “Remote Mode Status”
29 Status COS Mask Bit 29 Status COS Mask Bit 29 “Local Mode Status”
30 Status COS Mask Bit 30 Status COS Mask Bit 30 “Normal Mode Status”
31 Status COS Mask Bit 31 Status COS Mask Bit 31 “Test Mode Status”
