Parameters B-67
1503-UM054C-EN-P – June 2013
Drop Out Time Setting From IB4 DIP Switches
[IB 4 Drop Out Time DIP Setting]
Parameter Number: 121,104,_,_,_.
Access rule: Get
Data Type: USINT
Object Mapping: 0x384-4-49
Group: Configuration
Units: see table
Minimum Value: 0
Maximum Value: 7
Default Value: 0
This parameter allows the user to view the Drop Out Time Setting
set from the IB4 DIP switches. The Drop Out Time is initially set by
the IB4 DIP switches but can be over-ridden by Parameter #116 after
which time the original IB4 DIP switch settings will no longer be used.
Table B.26 – Drop Out Time Settings From IB4 DIP Switches
Value Enum Text Description
0 50 ms 50 ms from IB4 DIP switches
1 75 ms 75 ms from IB4 DIP switches
2 100 ms 100 ms from IB4 DIP switches
3 130 ms 130 ms from IB4 DIP switches
4 150 ms 150 ms from IB4 DIP switches
5 175 ms 175 ms from IB4 DIP switches
6 200 ms 200 ms from IB4 DIP switches
7 240 ms 240 ms from IB4 DIP switches
Note:
The drop off time would be 6mS longer if the close command
is applied on IB.
Drop Out Time Setting From IB5 DIP Switches
[IB 5 Drop Out Time DIP Setting]
Parameter Number: 122,_,_,_,_.
Access rule: Get
Data Type: USINT
Object Mapping: 0x384-5-49
Group: Configuration
Units: see table
Minimum Value: 0
Maximum Value: 7
Default Value: 0
This parameter allows the user to view the Drop Out Time Setting
set from the IB5 DIP switches. The Drop Out Time is initially set by
the IB5 DIP switches but can be over-ridden by Parameter #117 after
which time the original IB5 DIP switch settings will no longer be used.
