Drop Out Time Setting From IB1 DIP Switches
[IB 1 Drop Out Time DIP Setting]
Parameter Number:
118,101,84,67,49.
Access rule:
Get
Data Type:
USINT
Object Mapping:
0x384-1-49
Group:
Configuration
Units:
milliseconds
Minimum Value:
0
Maximum Value:
7
Default Value:
0
This parameter allows the user to view the Drop Out Time Setting
set from the IB1 DIP switches. The Drop Out Time is initially set by
the IB1 DIP switches but can be over-ridden by Parameter #113 after
which time the original IB1 DIP switch settings will no longer be
used.
Table B.23 – Drop Out Time Settings From IB1 DIP Switches
Value
Enum Text
Description
0
50 ms
50 ms from IB1 DIP switches
1
75 ms
75 ms from IB1 DIP switches
2
100 ms
100 ms from IB1 DIP switches
3
130 ms
130 ms from IB1 DIP switches
4
150 ms
150 ms from IB1 DIP switches
5
175 ms
175 ms from IB1 DIP switches
6
200 ms
200 ms from IB1 DIP switches
7
240 ms
240 ms from IB1 DIP switches
Drop Out Time Setting From IB2 DIP Switches
[IB 2 Drop Out Time DIP Setting]
Parameter Number:
119,102.85,68,_.
Access rule:
Get
Data Type:
USINT
Object Mapping:
0x384-2-49
Group:
Configuration
Units:
see table
Minimum Value:
0
Maximum Value:
7
Default Value:
0
This parameter allows the user to view the Drop Out Time Setting
set from the IB2 DIP switches. The Drop Out Time is initially set by
the IB2 DIP switches but can be over-ridden by Parameter #114 after
which time the original IB2 DIP switch settings will no longer be
used.
