B-52 Parameters
1503-UM054C-EN-P – June 2013
Override the Loss of an IO Connection [Comm Override]
Parameter Number: 92,80,68,56,43.
Access rule: Get/Set
Data Type: BOOL
Object Mapping: 0x1E-1-105
Group: Configuration
Units: -
Minimum Value: 0 = Disabled
Maximum Value: 1 = Enabled
Default Value: 1
This parameter allows the user to view and set the condition where
the local logic (DeviceLogix will override a DeviceNet
Communications Fault (ie. Communication loss or time out). If it is
disabled then the local logic (DeviceLogix) cannot override a
DeviceNet Communications Fault and it will cease operating. If it is
enabled then the logic (DeviceLogix) can override a DeviceNet
Communications Fault and it will continue to operate.
Type of Contactor Selected for IB1 [IB 1 Contactor Type]
Parameter Number: 93,81,69,57,44.
Access rule: Get
Data Type: USINT
Object Mapping: 0x384-1-14
Group: Configuration
Units: -
Minimum Value: 0
Maximum Value: 3
Default Value: 0
This parameter allows the user to view the status of the type of
contactor that is being controlled by the IB1 module. This value is
set by the DIP switches on the IB1 module only (see Table 8.C).
Table B.18 – Type of Contactor for IB1 Unit
Value Enum Text Description
0 400A Mech. Latch IB1 is a 400A Mechanically Latched contactor
1 400A Elec. Held IB1 is a 400A Electrically Held contactor
2 800A Mech. Latch IB1 is an 800A Mechanically Latched contactor
3 800A Elec. Held IB1 is an 800A Electrically Held contactor
