Table B.6 – DeviceLogix Programs
Bit
Enum Text
Description
0
User customized DeviceLogix
Prog.
Custom Logical operation – DEFAULT
1
FVR DeviceLogix Program
Full Voltage Reversing Starter
2
SMC DeviceLogix Program
Smart Motor Controller
3
RVR DeviceLogix Program
Reduced Voltage Reactor, Non-Reversing
Starter
4
RVAT DeviceLogix Program
Reduced Voltage Auto-Transformer, Non-
Reversing Starter
5
PFCC DeviceLogix Program
Reduced Voltage Auto-Transformer, Non-
Reversing Starter
6
Unused
7
unused
A detailed description of each of the DeviceLogix programs can be
found in Chapter 6.
Configuration of Control Inputs [Control Mask]
Parameter Number:
67,55,43,31,11.
Access rule:
Get/Set
Data Type:
USINT
Object Mapping:
0xB4-1-118
Group:
Control
Units:
-
Minimum Value:
2 = DeviceLogix
Maximum Value:
3 = HIM/PC
Default Value:
2
This parameter allows the user to view, as well as to select, the
Control Mask which defines the source of commands for the
IntelliVAC Plus to use. There are four different sources available
but only two can be selected for a 5 IB MC system. For each of the
Masks listed, a status of ‘0’ indicates that the Mask is disabled and a
status of ‘1’ indicates that the Mask is enabled.
Table B.7 – Control Masks
Bit
Enum Text
Description
0
Local
NOT ALLOWED
1
Network
NOT ALLOWED
2
DeviceLogix
Control from DeviceLogix
3
HIM/PC
Control from HIM/PC
4
Unused
5
Unused
6
Unused
7
Unused
A detailed description of each of the Control masks can be found in
Chapter 9, Logical Masks.
