Parameters B-183
1503-UM054C-EN-P – June 2013
MC System Locked [MC System Locked]
Parameter Number: 349,288,227,166,104.
Access rule: Get
Data Type: SINT
Object Mapping: 0xB4-1-130
Group: Diagnostics
Units: -
Minimum Value: 0
Maximum Value: 1
Default Value: 0
This parameter allows the user to view the status of the MC System
Locked state. If a bit is a ‘1’ then the fault or warning is present. If
a bit is a ‘1’ then the fault or warning is present. See Table 4.J in
Chapter 4 for a detailed description of the MC System Locked
feature.
Table B.46 – MC System Locked Operation
Bit Enum Text Description
0 Normal Normal operation – no faults/warnings on IB/IE/MC
1 Warning Warning(s) present on IB/IE/MC
2 Fault Fault(s) present on IB/IE/MC
3 Locked MC system in a locked state
Reset All Faults [Reset All Faults]
Parameter Number: 350,289,228,167,105.
Access rule: Get/Set
Data Type: BOOL
Object Mapping: 0xB4-1-131
Group: Diagnostics
Units: -
Minimum Value: 0 = No Operation
Maximum Value: 1 = Reset
Default Value: 0
This parameter allows the user to view as well as to Reset all Faults.
If this bit is ‘0’, then No Operation is performed. If this bit is ‘1’,
then a Reset operation is performed on all faults. If a fault is still
present then it will re-occur as soon as the Reset operation is
performed. See Reset in Chapter 4 for a detailed description of the
Reset operation.
