DeviceNet Information E-13
1503-UM054C-EN-P – June 2013
Table E.25 - Instance Attribute (cont.)
Parameter
No.
Control Parameter
Access
Rule
Type Description NV CCV
31 U/V with Close Command
Present
Get BOOL 0=not present
1=present
N N
32 Master Counter (Operations) Get UDINT 0~16777215 Y N
33 Reset Operations Since
Counter
Get/Set BOOL 0/1 Y N
34** Operations Event (count value) Get UDINT 0~16777215 Y N
35** Operations Event Since
(Date)
Get Date YYYY-MM-DD Y N
36** Operations Event Since
(Time)
Get Time HH-MM-SS.xxx Y N
37** Operations Since-1 Event
(count value)
Get UDINT 0~16777215 Y N
38** Operations Event Since-1
(Date)
Get Date YYYY-MM-DD Y N
39** Operations Event Since-1
(Time)
Get Time HH-MM-SS.xxx Y N
40** Operations Since-2 Event
(count value)
Get UDINT 0~16777215 Y N
41** Operations Event Since-2
(Date)
Get Date YYYY-MM-DD Y N
42** Operations Event Since-2
(Time)
Get Time HH-MM-SS.xxx Y N
43 Average Operations per Time
Unit
Get/Set USINT 0=Hour
1=Day
2=Week
Y N
44 Average Operations counter Get UDINT 0~16777215 Y N
45 Line Undervoltage Close Get BOOL 0=not present
1=present
N N
46 Line Overvoltage Get BOOL 0=not present
1=present
N N
47 Power Loss Get BOOL 0=not present
1=present
N N
48 Main Coil Open Get BOOL 0=not present
1=present
N N
49 Drop out time(from IB DIP) Get USINT 50/75/100/130/150/
175/200/240
N N
50 TDUV Time Get/Set USINT* 0.2 ~ 2.00 N N
51 Event Max Length Get SINT 100~500, depends on
the product option.
N N
52 Event log present length Get USINT 0-500, depends on
the product option.
Y N
53 Specific Event data Get
Member
Struct of
USINT
USINT
DATE
Time of Day
8 bytes
Event Code
Evnet Fault byte
Date
Time
Y N
54 Long Close Time Get BOOL 0=not present
1=present
N N
55 Extended Pick up Time Get BOOL 0=not present
1=present
N N
56 IB Contactor Not Healthy Get BOOL 0=not present
1=present
N N
57 Trip coil open Get BOOL 0=not present
1=present
N N
