Allied Telesis AlliedView-EMS 4.0.1 DEVICE MANAGEMENT User Manual
Page 408
LED
State
Description
DUPLEX Green
Orange
The port is operating at full-duplex.
The port is operating at half-duplex.
AT-STACKM
Note
- There are no LEDs on this module.
AT-A45/AT-A47/AT-STACKM
Note
- There are no LEDs on this module.
Note
- This image is only used on devices whose firmware does not allow Device Manager
to differentiate the AT-A45, AT-A47 and AT-STACKM uplink modules from each other.
AT-A60/AT-A60i (AT-XEM-1XP)
Note
- There are no LEDs on these modules.
AlliedView™-EMS 4.0.1 Device Management Guide
Page 408 of 411
