GDS-2000A Programming Manual
96
Related
Commands :MEASure:SOURce
Return parameter Returns the area value.
Chan Off Indicates the source channel is not
activated.
Note Before using this command, select the
measurement channel. See the example below.
Example :MEASure:SOURce1 CH1
:MEASure:AREa?
1.958E-03
Selects Channel 1, and then measures the area.
:MEASure:CARea
Description Returns the voltage/current area over one full
period.
Syntax :MEASure:CARea{?}
Related
Commands :MEASure:SOURce
Return parameter Returns the area value.
Chan Off Indicates the source channel is not
activated.
Note Before using this command, select the
measurement channel. See the example below.
Example :MEASure:SOURce1 CH1
:MEASure:CARea?
1.958E-03
Selects Channel 1, and then measures the area.
Query
