COMMAND DETAILS
149
Example1 :TRIGger:LOGic:PATtern:WHEn FALSE
Set the logic to false.
Example2 :TRIGger:LOGic:PATtern:WHEn?
FALSE
:TRIGger:TIMEOut:WHEn
Description Sets or queries the timeout trigger condition.
Syntax :TRIGger:TIMEOut:WHEn {HIGH|LOW|EITher|?}
Related
commands :TRIGger:TIMEOut:TIMER
Parameter HIGH Signal is high.
LOW Signal is low.
EITher Signal is high or low.
Return parameter Returns the timeout condition (HIGH, LOW, EITHER).
Example1 :TRIGger:TIMEOut:WHEn LOW
Sets the timeout condition to low.
:TRIGger:TIMEOut:TIMER
Description Sets or returns timeout trigger time.
Syntax :TRIGger:TIMEOut:TIMER {value | ? }
Related
commands :TRIGger:TIMEOut:WHEn
Parameter/Return
parameter Timeout time. (10nS to 10S).
Example :TRIGger:TIMEOut:TIMER?
8.960e-05
Set
Query
Set
Query
