GDS-2000A Programming Manual
222
:SEARCH:TRIGger:BUS:B1:LIN:IDentifier:
VALue
Description Sets or returns the binary address string to be used
for the LIN search trigger.
Note: Only applicable when the condition is set to
DATA or IDANDDATA.
Requirements: Firmware version V1.19 or later with
DS2-LA8 (or DS2-LA16).
Syntax :SEARCH:TRIGger:BUS:B1:LIN:IDentifier:VALue
{|?}
Parameter/
Return parameter The size of the string depends on the
data size setting. The string must be
enclosed in double quotes, “string”.
String contents:
x = don’t care
1 = binary 1
0 = binary 0
Example :SEARCH:TRIGger:BUS:B1:LIN:CONDition ID
:SEARCH:TRIGger:BUS:B1:LIN:IDentifier:VALue
"00X1X01X"
:SEARCH:TRIGger:BUS:B1:LIN:IDentifier:VALue?
>01100X1X01X
Set
Query
