COMMAND DETAILS
71
Example :CURSor:XY:POLar:RADIUS:POSition?
80.0E-3
Returns the polar radius position as 80.0mV.
:CURSor:XY:POLar:RADIUS:DELta
Description Returns the radius delta value of cursor 1 and 2.
Syntax :CURSor:XY:POLar:RADIUS:DELta {?}
Return Parameter Returns the radius delta.
Example :CURSor:XY:POLar:RADIUS:DELta?
31.4E-3
Returns the radius delta as 31.4mV.
:CURSor:XY:POLar:THETA:POSition
Description Queries the polar angle for the specified cursor in
XY mode, where X can be either 1 or 2.
Syntax :CURSor:XY:POLar:THETA:POSition {?}
Parameter 1, 2 (Cursor 1, Cursor 2)
Return parameter Returns the polar angle.
Example :CURSor:XY:POLAR:RADIUS:POSition1?
8.91E+1
Returns the polar angle for cursor1 as 89.1˚.
:CURSor:XY:POLar:THETA:DELta
Description Queries the polar angle delta between cursor1 and
cursor2.
Syntax :CURSor:XY:POLar:THETA:DELta {?}
Query
Query
Query
