COMMAND DETAILS
59
Parameter RECTangular Rectangular window
HAMming Hamming window
HANning Hanning window
BLAckman Blackman window
Return parameter Returns the FFT window.
Example :MATH:FFT:WINDow HAMming
Sets the FFT window filter to hamming.
:MATH:FFT:POSition
Description Sets the vertical position of the displayed FFT
result.
Syntax MATH:FFT:POSition { | ? }
Parameter Vertical position: -12e+0 to +12e+0
(12 units/division to +12 units/division.)
Return parameter Returns the vertical position.
Example :MATH:FFT:POSition -2e-1
Sets the FFT position to -0.2 divisions.
:MATH:FFT:SCALe
Description Sets the vertical scale of the displayed FFT result.
Syntax :MATH:FFT:SCALe { | ?}
Parameter Vertical scale:
Linear: 2e-3 to 1e+ (32mV~1kV)
dB: 1e+0 to 2e+1 (1~20dB)
Return parameter Returns vertical scale.
Example :MATH:FFT:SCAle 1.0e+0
Sets the scale to 1dB.
Set
Query
Set
Query
