COMMAND DETAILS
207
:SEARCH:TRIGger:BUS:B1:UART:RX:DATa:
VALue
Description Sets or queries the search triggering data value for
the UART bus when the bus is set to trigger on Rx
Data.
Syntax :SEARCH:TRIGger:BUS:B1:UART:RX:DATa:VALue
{string | ? }
Related
commands :SEARCH:TRIGger:BUS:B1:UART:RX:DATa:SIZe
Parameter The number of characters in the string
depends on the data size setting. The
string must be enclosed in double
quotes, "string".
x = don’t care
1 = binary 1
0 = binary 0
Return Parameter Returns the data value.
Example1 :SEARCH:TRIGger:BUS:B1:UART:CONDition RXDATA
:SEARCH:TRIGger:BUS:B1:UART:RX:DATa:SIZe 1
:SEARCH:TRIGger:BUS:B1:UART:RX:DATa:VALue
"1x1x0101"
Sets the value to 1x1x0101
Example 2 :SEARCH:TRIGger:BUS:B1:UART:RX:DATa:VALue?
1X1X0101
:SEARCH:TRIGger:BUS:B1:UART:TX:DATa:
SIZe
Description Sets or queries the number of bytes for UART data.
Note This setting only applies when the UART search
trigger is set to trigger on Tx Data
Set
Query
Set
Query
