GDS-2000A Programming Manual
144
Example1 :TRIGger:BUS:B1:SPI:CONDition MISO
:TRIGger:BUS:B1:SPI:DATa:SIZe 2
:TRIGger:BUS:B1:SPI:DATa:MISO:VALue "1x1x0101"
Sets the value to 1x1x0101
Example 2 :TRIGger:BUS:B1:SPI:DATa:MISO:VALue?
1X1X0101
:TRIGger:BUS:B1:SPI:DATa:MOSI:VALue
Description Sets or queries the triggering data value for the SPI
bus when the bus is set to trigger on MOSI or
MISO/MOSI.
Syntax :TRIGger:BUS:B1:SPI:DATa:MOSI:VALue {string | ? }
Related
commands :TRIGger:BUS:B1:SPI:DATa:SIZe
Parameter The number of characters in the string
depends on the data size setting. The
string must be enclosed in double
quotes, "string".
x = don’t care
1 = binary 1
0 = binary 0
Return Parameter Returns the data value.
Example1 :TRIGger:BUS:B1:SPI:CONDition MOSI
:TRIGger:BUS:B1:SPI:DATa:SIZe 2
:TRIGger:BUS:B1:SPI:DATa:MOSI:VALue "1x1x0101"
Sets the value to 1x1x0101
Example2 :TRIGger:BUS:B1:SPI:DATa:MOSI:VALue?
1X1X0101
Set
Query
