GDS-2000A Programming Manual
150
:TRIGger:BUS:B1:CAN:CONDition
Description Sets or returns the CAN trigger condition.
Requirements: Firmware version V1.19 or later with
DS2-LA8 (or DS2-LA16).
Syntax :TRIGger:BUS:B1:CAN:CONDition
{SOF|FRAMEtype|IDentifier|DATA|IDANDDATA|EOF|
ACKMISS|STUFFERR|?}
Parameter/
Return parameter SOF Triggers on a start of frame
FRAMEtype Triggers on the type of frame
Identifier Triggers on a matching identifier
DATA Triggers on matching data
IDANDDATA Triggers on matching identifier and
data field
EOF Triggers on the end of frame
ACKMISS Triggers on a missing acknowledge
STUFFERR Triggers on a bit stuffing error
Example1 :TRIGger:BUS:B1:CAN:CONDition SOF
Triggers on a start of frame.
Example2 :TRIGger:BUS:B1:CAN:CONDition?
>SOF
:TRIGger:BUS:B1:CAN:FRAMEtype
Description Sets or returns the frame type for a CAN
FRAMEType trigger.
Requirements: Firmware version V1.19 or later with
DS2-LA8 (or DS2-LA16).
Syntax :TRIGger:BUS:B1:CAN:FRAMEtype
{DATA|REMote|ERRor|OVERLoad|?}
Parameter/ DATA Sets the frame type to data frame
Set
Query
Set
Query
