COMMAND DETAILS
203
:SEARCH:TRIGger:BUS:B1:I2C:ADDRess:V
ALue
Description Sets or queries the I 2 C bus address value when the
I 2 C search trigger is set to trigger on Address or
Address/Data.
Syntax :SEARCH:TRIGger:BUS:B1:I2C:ADDRess:VALue
{string | ? }
Related
commands :SEARCH:TRIGger:BUS:B1:I2C:ADDRess:MODe
Parameter 7/10 characters, must be enclosed in
double quotes "string".
x = don’t care
1 = binary 1
0 = binary 0
Return Parameter Returns the address value in binary.
Example 1 :SEARCH:TRIGger:BUS:B1:I2C:ADDRess:MODe
ADDR7
:SEARCH:TRIGger:BUS:B1:I2C:ADDRess:VALue
"xxx0101"
Sets the address to XXX0101
Example 2 :SEARCH:TRIGger:BUS:B1:I2C:ADDRess:VALue?
XXX0101
:SEARCH:TRIGger:BUS:B1:I2C:ADDRess:DI
Rection
Description Sets or queries the address bit as read write or
don’t care for the search function.
Note This setting only applies when the I 2 C search
trigger is set to trigger on Address or
Address/Data
Set
Query
Set
Query
