COMMAND DETAILS
147
Return parameter Returns a string containing the conditions for a
logic pattern trigger.
Example :TRIGger:LOGic:PATtern?
:TRIGGER:LOGIC:PATTERN:INPUT:D0 X;D1
X;D2 X;D3 X;D4 X;D5 X;D6 X;D7 X;D8 X;D9 X;
D10 X;D11 X;D12 X;D13 X;D14 X;D15
X;:TRIGGER:LOGIC:PATTERN:WHEN
TRUE; :TRIGGER:LOGIC:PATTERN:DELTATIME
1.000e-08;
:TRIGger:LOGic:PATtern:INPut:D
Description Sets or queries the trigger logic for the selected
digital input.
Syntax :TRIGger:LOGic:PATtern:INPut:D { HIGH | LOW |
X | ? }
Related
commands :TRIGger:LOGic:INPut:CLOCK:SOURce
:TRIGger:LOGic:INPut:CLOCK:EDGe
Parameter X is the digital channel number
D(0~15)
HIGH Set to a high logic state
LOW Set to a low logic state
X Set to a "don’t care" state.
Return parameter Returns the logic state of the selected channel (HIGH,
LOW, X).
Example1 :TRIGger:LOGic:PATtern:INPut:D0?
X
:TRIGger:LOGic:PATtern:DELTatime
Description Sets or returns the pattern trigger delta time value.
Syntax :TRIGger:LOGic:PATtern:DELTatime { | ? }
Set
Query
Set
Query
