GDS-2000A Programming Manual
146
Parameter/Return
parameter AND AND logic trigger
NAND NAND logic trigger
NOR NOR logic trigger
OR OR logic trigger
Example TRIGger:LOGic:FUNCtion AND
Sets the logic function to AND.
:TRIGger:LOGic:INPut:CLOCK:SOURce
Description Sets or queries which channel is used as the clock
source.
Note When “NONe” is selected as the clock source the
trigger will use the Pattern trigger type. (This is the
equivalent of the Data trigger on the scope panel)
Syntax :TRIGger:LOGic:INPut:CLOCK:SOURce {NONe | D0 |
D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D 9 | D10 | D11 |
D12 | D13 | D14 | D15 | ? }
Related
commands :TRIGger:LOGic:INPut:CLOCK:SOURce
:TRIGger:LOGic:INPut:CLOCK:EDGe
Parameter/Return
parameter NONe No clock source, Set to pattern (data)
trigger.
D0 to D15 Digital channels D0 to D15
Example1 :TRIGger:LOGic:INPut:CLOCK:SOURce D0
:TRIGger:LOGic:INPut:CLOCK:EDGe FALL
:TRIGger:LOGic:PATtern
Description Returns the conditions that are used to generate a
logic pattern trigger with respect to the defined
input pattern and identifies the time at which the
selected pattern may be true and still generate a
trigger.
Syntax :TRIGger:LOGic:PATtern?
Set
Query
Query
