COMMAND DETAILS
213
IDANDDATA Sets search to trigger on matching
identifier and data field
EOF Sets search to trigger on the end of
frame
ACKMISS Sets search to trigger on a missing
acknowledge
STUFFERR Sets search to trigger on a bit stuffing
error
Example1 :SEARCH:TRIGger:BUS:B1:CAN:CONDition SOF
Triggers search on a start of frame.
Example2 :SEARCH:TRIGger:BUS:B1:CAN:CONDition?
>SOF
:SEARCH:TRIGger:BUS:B1:CAN:FRAMEtype
Description Sets or returns the frame type for the CAN
FRAMEType search trigger.
Requirements: Firmware version V1.19 or later with
DS2-LA8 (or DS2-LA16).
Syntax :SEARCH:TRIGger:BUS:B1:CAN:FRAMEtype
{DATA|REMote|ERRor|OVERLoad|?}
Parameter/
Return parameter DATA Sets the frame type to data frame
REMote Sets the frame type to remote frame
ERRor Sets the frame type to error frame
OVERLoad Sets the frame type to overload
Example :SEARCH:TRIGger:BUS:B1:CAN:FRAMEtype DATA
Sets the frame type to DATA.
Set
Query
