GDS-2000A Programming Manual
136
:TRIGger:BUS:B1:I2C:ADDRess:MODe
Description Sets or queries the I 2 C addressing mode (7 or 10
bits).
Syntax :TRIGger:BUS:B1:I2C:ADDRess:MODe {ADDR7 |
ADDR10 | ? }
Related
commands :TRIGger:BUS:B1:I2C:CONDition
Parameter ADDR7 7 bit addressing
ADDR10 10 bit addressing
Return Parameter 0 7 bit addressing
1 10 bit addressing
Example :TRIGger:BUS:B1:I2C:ADDRess:MODe?
0
The addressing mode is current set to 7 bits.
:TRIGger:BUS:B1:I2C:ADDRess:TYPe
Description Sets the I 2 C bus address type, or queries what the
setting is.
Syntax :TRIGger:BUS:B1:I2C:ADDRess:TYPe {GENeralcall |
STARtbyte | HSmode | EEPROM | CBUS | ?}
Related
commands :TRIGger:BUS:B1:I2C:CONDition
Parameter GENeralcall Set a general call address (0000 000 0).
STARtbyte Set a start byte address. (0000 000 1)
HSmode Set a high-speed mode address.
(0000 1xx x)
EEPROM Set an EEPROM address.
(1010 xxx x)
CBUS Set a CBUS address. (0000 001 x)
Set
Query
Set
Query
