COMMAND DETAILS
111
Parameter Reference waveform 1, 2, 3 ,4.
Horizontal co-ordinates
Return parameter Returns the reference waveform position
Example :REF1:TIMebase:POSition -5.000E-5
Selects reference 1, and then sets the horizontal
position to -50us.
:REF:TIMebase:SCALe
Description Sets or returns the selected reference waveform
time base scale.
Syntax :REF:TIMebase:SCALe { | ?}
Related
commands :REF:DISPlay
Parameter Reference waveform 1, 2, 3 ,4.
Horizontal scale
Return parameter Returns the reference waveform scale.
Example :REF1:TIMebase:SCALe 5.00E-4
Selects reference 1, and then sets the horizontal
scale to 500us/div.
:REF:OFFSet
Description Sets or returns the selected reference waveform
vertical position (offset).
Syntax :REF:OFFSet { | ?}
Related
commands :REF:DISPlay
Parameter Reference waveform 1, 2, 3 ,4.
Vertical offset
Return parameter Returns the reference waveform vertical
position.
Set
Query
Set
Query
