GDS-2000A Programming Manual
164
Parameter S1~S20 Saves the setup to Set1~Set20
File path Saves the setup to disk to the specified
file path.
Example :SAVe:SETUp S1
Saves the current setup to Set1 in internal memory.
:SAVe:SETUp “Disk:/DS0001.SET”
Saves the current setup to DS0001.SET in the
external USB flash disk.
:SAVe:WAVEform
Description Saves a waveform to internal memory or to a
designated file path.
Related
commands :SAVe:WAVEform:FILEFormat
Syntax :SAVe:WAVEform {CH1~REF4, REF } |
{CH1~REF4, W1~W20} | {CH1~ALL, file path}
Parameter CH1~REF4, CH1~CH4, Math, REF1~4
1,2,3,4 (REF1, REF2, REF3, REF4)
W1~W20 Wave1~Wave20
ALL All the displayed waveforms on screen.
File path Saves the waveform(s) to disk or USB to
the specified file path.
Example 1 :SAVe:WAVEform CH1, REF2
Saves the channel1 waveform to REF2.
Example 2 :SAVe:WAVEform:FILEFormat LSF
:SAVe:WAVEform ALL, “Disk:/ALL001”
Sets the file format to LSF. A folder named
“ALL001” is created and saves all displayed
waveforms to the “ALL001” directory in the LSF
format.
Set
