GDS-2000A Programming Manual
212
Related
commands :BUS1:PARallel:WIDth
Parameter The number of characters in the string
depends on the data size setting. The
string must be enclosed in double
quotes "string".
x = don’t care
1 = binary 1
0 = binary 0
Return Parameter Returns the data value.
Example 1 :BUS1:PARallel:WIDth 8
:SEARCH:TRIGger:BUS:B1:PARallel:VALue "1x1x0101"
Sets the value to 1x1x0101
Example 2 :SEARCH:TRIGger:BUS:B1:PARallel:VALue?
1X1X0101
:SEARCH:TRIGger:BUS:B1:CAN:CONDition
Description Sets or returns the CAN search trigger condition.
Requirements: Firmware version V1.19 or later with
DS2-LA8 (or DS2-LA16).
Syntax :SEARCH:TRIGger:BUS:B1:CAN:CONDition
{SOF|FRAMEtype|IDentifier|DATA|IDANDDATA|EOF|
ACKMISS|STUFFERR|?}
Parameter/ Return
parameter SOF Sets search to trigger on a start of
frame
FRAMEtype Sets search to trigger on the type of
frame
Identifier Sets search to trigger on a matching
identifier
DATA Sets search to trigger on matching data
Set
Query
