GDS-2000A Programming Manual
224
Parameter Digital channel number D(0 to 15).
Position
Return parameter Returns the position of the selected
digital channel.
Example1 :D0:POSition?
-1.87 DIV
Example2 :D0:POSition 0
Sets the position to 0 DIV.
:DISPlay:DIGital:HEIght
Description Sets or queries the height of the digital channel
waveforms.
Syntax :DISPlay:DIGital:HEIght {SMAll | MEDium | LARge | ?}
Parameter/
Return parameter SMAll Sets the height to small mode.
MEDium Sets the height to medium mode.
LARge Sets the height to large mode. This
mode is only available for ≤8 active
channels.
Example :DISPlay:DIGital:HEIght?
LARGE
:DIGital:GROUP:THREshold
Description Sets or returns the threshold level for the selected
group for a logic analyzer function.
Syntax :DIGital:GROUP:THREshold { ECL | TTL | PECL |
CMOS5 | CMOS3 | CMOS2 | | ? }
Set
Query
Set
Query
