GDS-2000A Programming Manual
192
Return parameter Returns the high level search trigger.
Example1 :SEARCH:TRIGger:HLEVel TTL
Sets the high level search trigger to TTL
Example2 :SEARCH:TRIGger:HLEVel 3.30E-1
Sets the high level search trigger to 330mV/mA.
:SEARCH:TRIGger:LLEVel
Description Sets or queries the low level search trigger.
Note Applicable for Rise and Fall/Pulse Runt triggers.
Syntax :SEARCH:TRIGger:LLEVel {TTL | ECL | | ?}
Related
commands :SEARCH:TRIGger:TYPe
Parameter Low level value.
TTL Sets the low trigger level to TTL.
ECL Sets the low trigger level to ECL.
Return parameter Returns the low level.
Example :SEARCH:TRIGger:LLEVel TTL
Sets the low level search trigger to TTL.
Example :SEARCH:TRIGger:LLEVel -3.30E-3
Sets the low level search trigger to 330mV/mA.
:SEARCH:TRIGger:PULSEWidth:POLarity
Description Sets or queries the pulse width search trigger
polarity.
Syntax :SEARCH:TRIGger:PULSEWidth:POLarity
{POSitive | NEGative | ?}
Related
commands :SEARCH:TRIGger:TYPe
Set
Query
Set
Query
