GDS-2000A Programming Manual
124
Description Sets or queries the high trigger level.
Note Applicable for Rise and Fall/Pulse Runt triggers.
Syntax :TRIGger:HLEVel {TTL | ECL| | | ?}
Related
commands :TRIGger:TYPe
Parameter High level value.
TTL Sets the high trigger level to TTL.
ECL Sets the high trigger level to ECL.
Return parameter Returns the trigger high level.
Example1 :TRIGger:HLEVel TTL
Sets the trigger high level to TTL.
Example2 :TRIGger:HLEVel 3.30E-1
Sets the trigger high level to 330mV/mA.
:TRIGger:LLEVel
Description Sets or queries the low trigger level.
Note Applicable for Rise and Fall/Pulse Runt triggers.
Syntax :TRIGger:LLEVel {TTL | ECL| | ?}
Related
commands :TRIGger:TYPe
Parameter Low level value.
TTL Sets the low trigger level to TTL.
ECL Sets the log trigger level to ECL.
Return parameter Returns the trigger low level.
Example1 :TRIGger:LLEVel TTL
Sets the trigger low level to TTL.
Example2 :TRIGger:LLEVel -3.30E-3
Sets the trigger low level to -330mV/mA.
Set
Query
