GW Instek GDS-2000A series Programming Manual - Manual (Page 95)

COMMAND DETAILS
95
Chan Off Indicates the source channel is not
activated.
Note Before using this command, select the
measurement channel. See the example below.
Example :MEASure:SOURce1 CH1
:MEASure:PK2Pk?
2.04E-1
Selects Channel 1, and then measures the peak-to-
peak amplitude.
:MEASure:RMS
Description Returns the root-mean-square voltage/current of
one or more full periods.
Syntax :MEASure:RMS{?}
Related
Commands :MEASure:SOURce
Return parameter Returns the RMS value.
Chan Off Indicates the source channel is not
activated.
Note Before using this command, select the
measurement channel. See the example below.
Example :MEASure:SOURce1 CH1
:MEASure:RMS?
1.31E-3
Selects Channel 1, and then measures the RMS
voltage/current.
:MEASure:AREa
Description Returns the voltage/current area over one or more
full periods.
Syntax :MEASure:AREa{?}
Query
Query
