COMMAND DETAILS
195
Example :SEARCH:TRIGger:PULSe:TIMe 4.00E-5
Sets the pulse width search trigger to 40.0us.
:SEARCH:TRIGger:RUNT:WHEn
Description Sets or queries the pulse runt search trigger
conditions.
Syntax :SEARCH:TRIGger:RUNT:WHEn {WHENthan |
LESSthan | EQual | UNEQual | ? }
Related
commands :SEARCH:TRIGger:TYPe
:SEARCH:TRIGger:RUNT:TIMe
Parameter MOREthan >
LESSthan <
Equal =
UNEQual ≠
Return parameter Returns the pulse runt search trigger conditions.
Example :SEARCH:TRIGger:RUNT:WHEn UNEQual
Sets the pulse runt search trigger condition to
unequal (≠).
:SEARCH:TRIGger:RUNT:TIMe
Description Sets or queries the pulse runt search trigger time.
Syntax :SEARCH:TRIGger:RUNT:TIMe { | ? }
Related
commands :SEARCH:TRIGger:TYPe
:SEARCH:TRIGger:RUNT:WHEn
Parameter Pulse runt time (4nS to 10S)
Return Parameter Returns the runt time in seconds.
Example :SEARCH:TRIGger:RUNT:TIMe 4.00E-5
Sets the pulse runt time to 40.0uS.
Set
Query
Set
Query
