COMMAND DETAILS
211
:SEARCH:TRIGger:BUS:B1:SPI:DATa:MOSI:
VALue
Description Sets or queries the search triggering data value for
the SPI bus when the bus is set to trigger on MOSI
or MISO/MOSI.
Syntax :SEARCH:TRIGger:BUS:B1:SPI:DATa:MOSI:VALue
{string | ? }
Related
commands :SEARCH:TRIGger:BUS:B1:SPI:DATa:SIZe
Parameter The number of characters in the string
depends on the data size setting. The
string must be enclosed in double
quotes, "string".
x = don’t care
1 = binary 1
0 = binary 0
Return Parameter Returns the data value.
Example1 :SEARCH:TRIGger:BUS:B1:SPI:CONDition MOSI
:SEARCH:TRIGger:BUS:B1:SPI:DATa:SIZe 2
:SEARCH:TRIGger:BUS:B1:SPI:DATa:MOSI:VALue
"1x1x0101"
Sets the value to 1x1x0101
Example2 :SEARCH:TRIGger:BUS:B1:SPI:DATa:MOSI:VALue?
1X1X0101
:SEARCH:TRIGger:BUS:B1:PARallel:VALue
Description Sets or queries the search triggering data value for
the Parallel bus.
Syntax :SEARCH:TRIGger:BUS:B1:PARallel:VALue {string | ? }
Set
Query
Set
Query
