GDS-2000A Programming Manual
228
:DIGital:MEMory
Description
Returns the data in acquisition memory for the
digital channels as a header + raw data.
Syntax
:DIGital:MEMory?
Related
commands
ACQuire:RECOrdlength
:HEADer
Return parameter
Returns the raw data + header information for the
digital channels in the following format:
Format,2.0A,Display,0000000000001100,Memory
Length,5000,IntpDistance,0,Trigger
Address,2500,Threshold12_15,1.400E+00,Threshol
d8_11,1.400E+00,Threshold4_7,1.400E+00,Threshol
d0_3,1.400E+00,Vertical
Units,V,Label15,;Label14,;Label13,;Label12,;Label1
1,;Label10,;Label9,;Label8,;Label7,;Label6,;Label5,;
Label4,;Label3,;Label2,;Label1,;Label0,;Firmware,V
0.99.03,Horizontal Units,S,Horizontal Scale,5.000E-
04,Horizontal Position,0.000E+00,Horizontal
Mode,Main,SincET Mode,Real Time,Sampling
Period,1.000E-06,Time,25-Sep-12
16:42:09,Waveform Data;
:DIGital:LMEMory
Description
Returns the data in acquisition memory for the digital
channels as a header + raw data.
Note
The data from this command is equivalent to the data
that is saved in the LM Detail format using the scope
panel controls.
Syntax
:DIGital:LMEMory?
Related
commands
ACQuire:RECOrdlength
:HEADer
Query
Query
