GDS-2000A Programming Manual
56
:MATH:TYPe
Description Queries or sets the Math type to FFT, Advanced
Math or to dual channel math operations
Syntax :MATH:TYPe { DUAL | ADVanced | FFT | ? }
Related
Commands :MATH:DISP
Parameter DUAL Dual channel operations
ADVanced Advanced math operations
FFT FFT operations
Return parameter Returns the math type.
Example :MATH:TYPe DUAL
Sets the Math type to dual channel math operation.
:MATH:DUAL:SOURce
Description Sets the dual math source for source 1 or 2.
Syntax :MATH:DUAL:SOURce { CH1 | CH2 | CH3 | CH4 |
REF1 | REF2 | REF3 | REF4 | ? }
Parameter Source number 1 or 2
CH1~4 Channel 1 to 4
REF1~4 Reference waveforms 1 to 4
Return parameter Returns the source for the source 1 or 2.
Example :MATH:DUAL:SOURce1 CH1
Sets source1 as channel 1.
:MATH:DUAL:OPERator
Description Sets the math operator for dual math operations.
Set
Query
Set
Query
Set
Query
