GDS-2000A Programming Manual
204
Syntax :SEARCH:TRIGger:BUS:B1:I2C:ADDRess:DIRection
{ READ | WRITE | NOCARE | ? }
Related
commands :SEARCH:TRIGger:BUS:B1:I2C:CONDition
Parameter READ Set read as the data direction.
WRITE Set write as the data direction.
NOCARE Set either as the data direction.
Return Parameter Returns the direction (READ, WRITE, NOCARE).
Example :SEARCH:TRIGger:BUS:B1:I2C:ADDRess:DIRection
READ
Sets the direction to READ.
:SEARCH:TRIGger:BUS:B1:I2C:DATa:SIZe
Description Sets or queries the data size in bytes for the I 2 C
bus.
Note This setting only applies when the I 2 C search
trigger is set to trigger on Data or Address/Data
Syntax :SEARCH:TRIGger:BUS:B1:I2C:DATa:SIZe { | ? }
Related
commands :SEARCH:TRIGger:BUS:B1:I2C:CONDition
Parameter Number of data bytes (1 to 5).
Return parameter Returns the number of bytes.
Example :SEARCH:TRIGger:BUS:B1:I2C:DATa:SIZe 3
Sets the number of bytes to 3.
:SEARCH:TRIGger:BUS:B1:I2C:DATa:VALue
Description Sets or queries the triggering data value for the I 2 C
bus when the I 2 C search trigger is set to trigger on
Data or Address/Data.
Set
Query
Set
Query
