70

Multi-Service IronWare Administration Guide

53-1003028-02

Displaying information for an interface for an Ethernet port

2

TABLE 18

Display of show interface ethernet port

This field...

Displays...

Module type port# is state

The module type variable specifies a type of interface module, such as
10GigabitEthernet.
The port# variable specifies the port number for the interface module.
The state variable if the interface module is up or down.

Line protocol is status

The status variable specifies if the line protocol is up or down.
If the interface is down due to Remote Fault, the reason is indicated as:
“(remote fault)”.
If a port is down because of a Local Fault, the reason is indicated as: “(local
fault)”.

STP Root Guard is status The

status variable specifies if the STP Root Guard is enabled or disabled.

STP BPDU Guard is status The

status variable specifies if the STP BPDU Guard is enabled or disabled.

Hardware is module type

The module type variable specifies a type of interface module, such as
#GigabitEthernet.

Address is MAC- address

The MAC- address variable specifies the MAC address of the port.

Configured speed and actual speed The speed that the module has been configured to operate at, and the

actual speed it is currently operating at.

Configured port speed and actual
duplex

The port capacity that the module has been configured to operate at, and
the actual speed it is currently operating at.

Member of VLAN # (untagged)
port# L2 VLANS (tagged)
Port is in dual
mode/untagged/tagged
mode
Port state is status

The VLAN# (untagged) variable specifies a port that is a member of only 1
VLAN.
The port# L2 VLANS (tagged) variable specifies a port that is a member of
multiple ports and untagged.
A port is in dual- mode specifies member VLAN ports as untagged and
tagged. The default mode is dual-mode.
The status variable identifies the flow of traffic as forwarding or disabled.

STP configured to status
Priority level
Flow control status

The status variable specifies if the STP is ON or OFF.
The priority level assigned to the port-based VLAN. The priority level is on
scale from 0-7. The default is 0.
The status variable is enabled or disabled.

Priority force status

The status variable specifies if the priority force on a port is disabled on
enabled.

Drop precedence level value

Identifies the TOS or DSCP value in the IPv4 or IPv6 packet header.
The value variable specifies the drop precedence on a scale from 0-3.
Packets that contain a DSCP value of 0 are least likely to be dropped and
packets with a value of 3 are most likely to be dropped. The default value is
0.

Drop precedence force status

The status variable specifies the drop precedence force as enabled or
disabled. Identifies the drop precedence if the force command is configured
for a specific ingress port.

arp-inspection-trust configured to
status

The status variable specifies if arp-inspection-trust feature is configured ON
or OFF. The default trust setting for a port is untrusted.

Mirror status

The status variable specifies if the port mirror command is configured as
enabled or disabled.

Monitor status

The status variable specifies if the port monitor command is configured as
enabled or disabled.
