54 Multi-Service IronWare Administration Guide
53-1003028-02
Configuring system max values
2
The mac parameter sets the maximum number of MAC entries.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The mgmt-port-acl-size parameter sets the maximum size for a management port ACL.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The subnet-broadcast-acl-cam parameter sets the maximum number of IP broadcast ACL CAM
entries. For minimum, maximum, and default values for this parameter, refer to
Table 9 .
The receive-cam parameter sets the maximum number of IP Receive ACL software CAM entries.
For minimum, maximum and default values for this parameter refer to
Table 9 .
The rstp parameter sets the maximum number of RSTP instances.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The session-limit parameter sets the maximum number of sessions.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The spanning-tree parameter sets the maximum number of spanning-tree instances.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The virtual-interface parameter sets the maximum number of virtual interfaces.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The vlan parameter sets the maximum number of VLANs.
For minimum, maximum and default values for this parameter refer to
Table 9 and Table 10 .
The vpls-mac parameter sets the maximum number of VPLS MAC Entries.
For minimum, maximum and default values for this parameter refer to
Table 9 .
The vpls-num parameter sets the maximum number of Virtual Private LAN Services (VPLS). For
minimum, maximum and default values for this parameter refer to
Table 9
The ecmp-pram-block-size parameter is used as a limiting factor when programing ECMP nexthops
(v4/v6/vpnv4/vpnv6).Even though the control plane supports up to 32 nexthops per a route, the
actual number of nexthops which are programmed in HW is controlled by this command.If
system-max ecmp-pram-block-size is configured to a value lesser than the value configured for ip
load-sharing or ipv6 load-sharing, or if ip load-sharing or ipv6 load-sharing is configured to a value
greater than that configured for system-max ecmp-pram-block-size, a warning message will be
displayed. For minimum, maximum and default values for this parameter refer to
Table 9
TABLE 11 System max ifl-cam values available by CAM profile on Brocade NetIron XMR and
Brocade MLX series
CAM profile Minimum value Maximum value Default value
Default 0 57344 8192
ipv4 0 114688 8192
ipv6 0 131072 8192
l2-metro 0 114688 8192
mpls-l3vpn 0 114688 8192
mpls-vpls 0 114688 8192
multi-service 0 49152 8192
multi-service-2 0 81920 8192
vpn-vpls 0 114688 8192
ipv4-vpn 0 114688 8192
