Show commands
7
Configuration Examples
The following sections lists configuration examples to configure the Brocade device.
NTP server and client mode configuration
Sample CLI commands to configure the NI device in NTP server and client modes.
Brocade(config-ntp)# server 10.1.2.3 minpoll 5 maxpoll 10
Brocade(config-ntp)# server 2001:db8::1/64
Brocade(config-ntp)# peer 10.100.12.18
Brocade(config-ntp)# peer 10.100.12.20
Brocade(config-ntp)# peer 10.100.12.67
Brocade(config-ntp)# peer 10.100.12.83
NTP client mode configuration
Sample CLI commands to configure the Brocadedevice in NTP client mode.
Brocade(config-ntp)# server 10.1.2.3 minpoll 5 maxpoll 10
Brocade(config-ntp)# server 2001:db8::1/24
Brocade(config-ntp)# peer 10.100.12.83
Brocade(config-ntp)# disable serve
NTP strict authentication configuration
Sample CLI commands to configure the Brocade device in strict authentication mode.
Brocade(config-ntp)# authenticate
Brocade(config-ntp)# authentication-key key-id1 md5 key123
Brocade(config-ntp)# server 10.1.2.4 key 1
NTP loose authentication configuration
Sample CLI commands to configure the NI device in loose authentication mode. This allows some
of the servers or clients to use the authentication keys.
Brocade(config-ntp)# authentication-key-id key-id1 md5 key123
Brocade(config-ntp)# server 10.1.2.4 key 1
Brocade(config-ntp)# server 10.1.2.7
version Peer NTP version number
org time Originate time stamp of the last packet.
rcv time Receive time stamp of the last packet.
xmt time Transmit time stamp of the last packet.
filter delay Round-trip delay in milliseconds of last 8 samples.
filter offset Clock offset in milliseconds of last 8 samples.
filter error Approximate error of last 8 samples
TABLE 39 show ntp associations detail command output descriptions
Field..... Description.....
