One-way Delay Measurement
6
Sample Configuration one-way delay measurement over VPLS
VPLS Configurations:
PE-1 Configuration
PE-1(config)# interface ethernet 1/1
PE-1(config-if-e10000-1/1)# enable
PE-1(config-if-e10000-1/1)# exit
PE-1(config)# router mpls
PE-1(config-mpls)# vpls vpls100 100
PE-1(config-mpls-vpls-vpls100)# vlan 10
PE-1(config-mpls-vpls-vpls100-vlan-10)# tagged ethernet 1/1
PE-1(config-mpls-vpls-vpls100-vlan-10)# end
PE-2 Configuration
PE-2(config)# interface ethernet 1/1
PE-2(config-if-e10000-1/1)# enable
PE-2(config-if-e10000-1/1)# exit
PE-2(config)# router mpls
PE-2(config-mpls)# vpls vpls100 100
PE-2(config-mpls-vpls-vpls100)# vlan 10
PE-2(config-mpls-vpls-vpls100-vlan-10)# tagged ethernet 1/1
PE-2(config-mpls-vpls-vpls100-vlan-10)# end
CFM Configurations:
PE-1 Configuration
PE-1(config)# cfm-enable
PE-1(config-cfm)# domain md1 level 7
PE-1(config-cfm-md-md1)# ma ma1 vpls 100 priority 4
PE-1(config-cfm-md-md1-ma-ma1)# mep 1 up vlan 10 port ethernet 1/1
PE-2 Configuration
PE-2(config)# cfm-enable
PE-2(config-cfm)# domain md1 level 7
PE-2(config-cfm-md-md1)# ma ma1 vpls 100 priority 4
PE-2(config-cfm-md-md1-ma-ma1)# mep 101 up vlan 10 port ethernet 1/1
One-way delay measurement configurations (common for VPLS)
NOTE
The one-way delay measurement receiver session should be started first before starting the initiator
session. Otherwise, the one-way delay measurement packets will be dropped at the receiver, which
may lead to inaccurate results.
CE-1 Configuration
CE-1(config)# cfm
CE-1(config-cfm)# oneway-dm initiator 1
CE-1(config-cfm-oneway-dm-initiator-1)#domain md1 ma ma1 src-mep 1 target-mep 2
CE-1(config-cfm-oneway-dm-initiator-1)#tx-interval 10
CE-2 Configuration
CE-2(config)# cfm
