246 Multi-Service IronWare Administration Guide
53-1003028-02
One-way Delay Measurement
6
The example above will be started exactly at 09:30 AM.
c. Start 1DM Receiver Session daily at given time.
DUT (config-cfm-oneway-dm-receiver-1)# start 09:30:00 daily
The example above will be started daily exactly at 09:30 AM.
Starting the one-way delay measurement session initiator
A session can be started immediately, after a specified amount of time, once at a specific time, or
a specific time daily.
DUT (config-cfm-oneway-dm-initiator-1)# start now
Syntax: start now | after HH:MM:SS | HH:MM:SS daily
Stopping the one-way delay measurement initiator session
A session can be stopped immediately, after a specified amount of time, once at a specific time, or
a specific time daily.
DUT (config-cfm-oneway-dm-initiator-1)# stop now
Syntax: stop now | after HH:MM:SS | HH:MM:SS daily
Stopping one-way delay measurement receiver session
A receiver session can be stopped immediately, after a specified amount of time, or at a specific
time.
DUT (config-cfm-oneway-dm-receiver-1)# stop now
Syntax: stop now | after HH:MM:SS | HH:MM:SS
NOTE
The one-way delay measurement Receiver session should be started before starting the one-way
delay measurement Initiator session. Also, the one-way delay measurement Initiator session should
be stopped before stopping the one-way delay measurement Receiver session.
NOTE
Relative time is converted to absolute time otherwise it would not point to the expected time after a
config-save and reboot. This case is applicable to both start and stop times.
Configuration examples
Sample configuration one-way delay measurement over VLAN
VLAN configurations:
CE-1 Configuration
CE-1(config)# interface ethernet 1/1
CE-1(config-if-e10000-1/1)# enable
CE-1(config-if-e10000-1/1)# exit
CE-1(config)# vlan 10
CE-1(config-vlan-10)# tagged ethernet 1/1
