Configuration examples, Configuration example 1 – Brocade Multi-Service IronWare Administration Guide (Supporting R05.6.00) User Manual
Page 108
90
Multi-Service IronWare Administration Guide
53-1003028-02
Configuration examples
3
Configuration examples
NOTE
Telemetry can also be configured from SNMP. Refer to the Unified IP MIB Reference guide for more
information.
Configuration example 1
FIGURE 4
Configuration example 1
ACL Definition
ip access-list extended xGW_Filter1
permit vlan 114 udp any eq 1066 any
ipv6 access-list xGW_Filter1
permit vlan 112 ipv6 2001:db8:200::/48 any
ip access-list extended xGW_Filter2
permit vlan 2405 ip host any
permit vlan 3000 ip any any
ACL Association and Path Naming
route-map xGW_map permit 1
rule-name xGW_path1
match ip address xGW_Filter1
match ipv6 address xGW_Filter1
set next-hop-flood-vlan 2 preserve-vlan
route-map xGW_map permit 2
rule-name xGW_path2
match ip address xGW_Filter2
set interface ethernet 15/1 preserve-vlan
Associate Path Policy to ingress
interface ethernet 10/1
ip policy route-map xGW_map
ipv6 policy route-map xGW_map
