328 Multi-Service IronWare Administration Guide
53-1003028-02
Using Syslog
A
This appendix describes how to display Syslog messages and how to configure the Syslog facility,
and lists the Syslog messages that a Brocade device can display during standard operation.
NOTE
This appendix does not list Syslog messages that can be displayed when a debug option is enabled.
A device’s software can write syslog messages to provide information at the following severity
levels:
• Emergencies
• Alerts
• Critical
• Errors
• Warnings
• Notifications
• Informational
• Debugging
The device writes the messages to a local buffer, which can hold up to 5000 entries.
You also can specify the IP address or host name of up to six Syslog servers. When you specify a
Syslog server, the device writes the messages both to the system log and to the Syslog server.
Using a Syslog server ensures that the messages remain available even after a system reload. The
device’s local Syslog buffer is cleared during a system reload or reboot, but the Syslog messages
sent to the Syslog server remain on the server.
The Syslog service on a Syslog server receives logging messages from applications on the local
host or from devices such as a Brocade MLX series. Syslog adds a time stamp to each received
message and directs messages to a log file. Most Unix workstations come with Syslog configured.
Some third party vendor products also provide Syslog running on NT.
Syslog uses UDP port 514 and each Syslog message thus is sent with destination port 514. Each
Syslog message is one line with Syslog message format. The message is embedded in the text
portion of the Syslog format. There are several subfields in the format. Keywords are used to
identify each subfield, and commas are delimiters. The subfield order is insensitive except that the
text subfield should be the last field in the message. All the subfields are optional.
Number of
Entries the
Local Buffer
Can Hold 1-5000 1-5000 1-5000 1-5000 1-5000 1-5000 1-5000
Disabing
Syslog for an
event Yes Yes Yes Yes Yes Yes Yes
TABLE 56 Supported Brocade Syslog features
Features
supported Brocade
NetIron XMR
Series Brocade
MLX Series Brocade
NetIron CES
2000 Series
BASE
package Brocade
NetIron CES
2000 Series
ME_PREM
package Brocade
NetIron CES
2000 Series
L3_PREM
package Brocade
NetIron CER
2000 Series
Base
package Brocade
NetIron CER
2000 Series
Advanced
Services
package
